Spesifikasi:

Processor / System Bus:
Per node:
2 x Socket E (LGA 4677)
4th Gen Intel® Xeon® Scalable processors
5th Gen Intel® Xeon® Scalable processors
(Air cool with EVAC up to 270W, with STD HSK up to 205W)

Generation: E11

Core Logic: Intel® C741

Memory:
Per node:
16 x DIMM slots
4th: DDR5 4800 MHz RDIMM/3DS RDIMM (1DPC)
5th: DDR5 5600/4800 MHz RDIMM/3DS RDIMM (1DPC)
512GB, 256GB, 128GB Intel® Optane™ persistent memory 300 series

Expansion Slots:
Per node:
Up to 2 slots
2 x PCIe x16 slot (Gen5 x16 link, HHHL)

Storage:
Per node:
SAS/SATA Controller :
LSI 3008 8-port SAS 12G Controller (Option)

Drive Bays:
8 x 2.5" Front Hot-swap drive bays
(Up to 8 x NVMe/SATA/SAS)*

Per node:
2 x M.2  (Up to 22110, SATA or Gen4 x2 link)

Networking:
Per node:
2 x Intel X710
1 x Management Port

Graphic: Aspeed AST2600 with 64MB VRAM

Rear I/O Ports:
Per Node:
2 x USB 3.1 ports
1 x VGA port
1 x RJ-45 GbE LAN ports
1 x RJ-45 Management port

Switch/LED:
Per Node:
Rear:
1 x Power Switch/LED
1 x Q-Code/Port 80 LED
Front:
1 x Power Switch/LED
1 x Location Switch/LED
1 x Message LED
2 x LAN LED

Dimensions:
800 x 444 x 88mm
31.5" x 17.48" x 3.46"

Form Factor: 2U

Weight:
Net Weight: 35.50 kg
Gross Weight: 41.50 kg

Power Supply:
1+1 Redundant 3000W 80 PLUS Titanium Power Supply
*1+1 redundant mode only supports CPUs under 205W
