Spesifikasi:
Chipset: AMD® B850
CPU Support:
Supports AMD Socket AM5 Processors including Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors
Memory Support:
4x DIMMS, Dual Channel DDR5, Maximum Memory Capacity 256GB (4x 64GB), up to 7600 MHz(OC)
PCI-E Expansion Slots: 1x PCIe 4.0 x16, 1x PCIe 4.0 x4
Display Connector: DisplayPort x1, HDMI x1
Audio: Realtek® ALC897 HD Audio, 5.1 Channel
Network:
Realtek® RTL8125BG 2.5 Gigabit Ethernet
M.2 WiFi 6 Module, Support 802.11 a/b/g/n/ac/ax, 2.4 GHz/ 5 GHz band, Bluetooth 5.3 Support
Front USB Headers:
1x USB 3.2 Gen1 (1 x Type-C), 1x USB 3.2 Gen1 (2 x Type-A), 2x USB 2.0 (4 x Type-A)
Rear Ports:
1× HDMI™, 1× DisplayPort, 6× USB 2.0, 2× USB 3.2 Gen1 Type-A
1× RJ45 LAN, 2× Wi Fi Antennas, 3× Audio Jacks
Storage: 1x PCIe 5.0 M.2, 1x PCIe 4.0 M.2, 4x SATA
Dimensions: Micro-ATX, 244x244mm
Debug LED: DRAM: Yellow, CPU: Red, GPU: White, Boot: Green
