Spesifikasi:
Chipset: AMD® A520
CPU Support:
Supports AMD Socket AM4 Processors including Ryzen™ 5000 / 4000 / 3000 Series Desktop Processors
Memory Support:
2x DIMMS, Dual Channel DDR4, Maximum Memory Capacity 64GB (2x 32GB)
PCI-E Expansion Slots: 1x PCIe 3.0 x16, 1x PCIe 3.0 x1
Display Connector: HDMI, D-Sub
Audio: Realtek® ALC897 HD Audio, 5.1 Channel
Network: Realtek® RTL8111M Gigabit Ethernet
Front USB Headers:
1x USB 3.2 Gen1 (2 x Type-A)
1x USB 2.0 (2 x Type-A)
Rear Ports:
1× HDMI™, 1× VGA, 1× PS/2
2× USB 2.0, 4× USB 3.2 Gen 1 Type-A
1× LAN ( RJ45), 3× Audio Jacks
Storage: 1x PCIe 3.0 M.2, 4x SATA
Dimensions: Micro-ATX, 230x197mm
Debug LED: DRAM: Yellow, CPU: Red, GPU: White, Boot: Green
