Card dimensions for PCIe slot 1~Slot 2：190 x 111.15 x 18.76 mm / 7.48 x 4.38 x 0.74 inches. Wider cards can be installed if the next PCIe slot will not be used.
USB 3.2 Gen 1 port
2
USB 3.2 Gen 2 (10Gbps) Port
2 x Type-A
HDMI™ Output
1, HDMI™ 2.0 (up to 3840 x 2160 @ 60Hz)
Form Factor
Tower
LED Indicators
HDD 1-6, Status, LAN, USB, M.2 SSD 1-2
Buttons
Power, Reset, USB Copy
Dimensions (HxWxD)
180.2 × 264.3 × 279.6 mm
Dimensions do not include foot pad (foot pad may be up to 30mm / 1.18 inches high depending on model)
Weight (Net)
7 kg
Weight (Gross)
7.8 kg
Operating Temperature
0 - 40 °C (32°F - 104°F)
Storage Temperature
-20 - 70°C (-4°F - 158°F)
Relative Humidity
5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Unit
250W, 100-240V AC, 50/60Hz, 3.5A
Power Consumption: Disk Standby Mode
41.897 W
Power Consumption: Operating Mode, Typical
60.794 W
Fan
3 x 80mm, 12VDC
System Warning
Buzzer
Kensington Security Slot
Standard Warranty
3
Max. Number of Concurrent Connections (CIFS) - with Max. Memory
2000
« Read Less
Share:
QNAP 6-BAY NAS, ZHAOXIN KX-U6580 8C/8T 2.5GHZ, 8GB DDR4 RAM (2 X SODIMM SLOTS, MAX. 64GB), 6X SATA 6
Spesifikasi:
TVS-675-8G
CPU
ZhaoXin KX-U6580 8-core 2.5GHz processor
CPU Architecture
64-bit x86
Graphic Processors
ZhaoXin C-960 Graphics
Floating Point Unit
Encryption Engine
(AES-NI)
Hardware-accelerated Transcoding
System Memory
8 GB SODIMM DDR4
Maximum Memory
64GB (2 x 32 GB)
Memory Slot
2 x SODIMM DDR4
For dual-DIMM configuration, you must use a pair of identical DDR4 modules.
Flash Memory
5GB (Dual boot OS protection)
Drive Bay
6 x 3.5-inch SATA 6Gb/s, 3Gb/s
Drive Compatibility
3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives
Card dimensions for PCIe slot 1~Slot 2：190 x 111.15 x 18.76 mm / 7.48 x 4.38 x 0.74 inches. Wider cards can be installed if the next PCIe slot will not be used.
USB 3.2 Gen 1 port
2
USB 3.2 Gen 2 (10Gbps) Port
2 x Type-A
HDMI™ Output
1, HDMI™ 2.0 (up to 3840 x 2160 @ 60Hz)
Form Factor
Tower
LED Indicators
HDD 1-6, Status, LAN, USB, M.2 SSD 1-2
Buttons
Power, Reset, USB Copy
Dimensions (HxWxD)
180.2 × 264.3 × 279.6 mm
Dimensions do not include foot pad (foot pad may be up to 30mm / 1.18 inches high depending on model)
Weight (Net)
7 kg
Weight (Gross)
7.8 kg
Operating Temperature
0 - 40 °C (32°F - 104°F)
Storage Temperature
-20 - 70°C (-4°F - 158°F)
Relative Humidity
5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Unit
250W, 100-240V AC, 50/60Hz, 3.5A
Power Consumption: Disk Standby Mode
41.897 W
Power Consumption: Operating Mode, Typical
60.794 W
Fan
3 x 80mm, 12VDC
System Warning
Buzzer
Kensington Security Slot
Standard Warranty
3
Max. Number of Concurrent Connections (CIFS) - with Max. Memory
