Spesifikasi :
Model : TUF Gaming BE3600 (TUF-BE3600)
Network Standard
- IEEE 802.11a
- IEEE 802.11b
- IEEE 802.11g
- WiFi 4 (802.11n)
- WiFi 5 (802.11ac)
- WiFi 6 (802.11ax)
- WiFi 7 (802.11be)
- IPv4
- IPv6
Product Segment : BE3600 ultimate BE performance : 688+2882 Mbps
WiFi Data Rate :
- WiFi 6 (802.11ax) (5GHz) : up to 2402 Mbps
- WiFi 7 (802.11be) (2.4GHz): up to 688 Mbps
- WiFi 7 (802.11be) (5GHz): up to 2882 Mbps
Antenna : External antenna x 4
Transmit / Receive :
Processor : 2.0 GHz quad-core processor
Memory :
Boosts Speed :
- OFDMA (Orthogonal Frequency Division Multiple Access)
- Beamforming: standard-based and universal
- 4096-QAM high data rate
- 20/40/80/160 MHz bandwidth
Operating Frequency :
Operating Mode :
- Wireless router mode
- Access point mode
- Media bridge mode
I/O Ports :
- 1x 2.5G for WAN/LAN,
- 1x 1G for WAN/LAN,
- 3 x 1G LAN,
- USB 3.2 Gen 1 x 1
Buttons : WPS Button, Reset Button, Power Button
LED Indicator :
- Power x 1
- WAN x 1
- LAN x 1
- 2.4GHz WiFi x 1
- 5GHz WiFi x 1
Power Supply :
- AC Input : 100V~240V (50~60Hz)
- DC Output : 12 V with max. 2 A current
Package Content :
- TUF Gaming BE3600 Dual Band WiFi 7 router
- RJ-45 cable
- Power adapter
- Quick Start Guide
- Warranty card
Product Weight (g) : 561g
Product Dimensions : 274 x 168 x 205 mm
AiMesh :
- AiMesh
• Primary AiMesh Router
• AiMesh Node
Game :
- Game Boost / Acceleration
- Mobile Game Mode
- Gaming Port
Parental Control :
- Time Scheduling
- Safe Browsing
- Customized Internet Schedule
Guest Network :
- "The Guest Network provides Internet connection for guests but restricts access to your local network."
• Maximum Guest Network Rule : 2.4GHz x3, 5GHz x3 - Guest Network Connection Time Limit
Security :
- AiProtection
- VPN
- WPS support, WPA/WPA2/WPA3-Personal,
- WPA/WPA2-Enterprise
- WPS
- Let's Encrypt
- DNS-over-TLS
- SSH
- Security Scan
- Firewall
• Maximum Firewall Keyword Filter : 64
• Maximum Firewall Network Service Filter : 32
• Maximum Firewall URL Filter : 64
AiProtection :
- AiProtection
• Router Security Assessment
• Malicious Site Blocking
• Two-Way IPS
VPN :
- Instant Guard
- VPN Client L2TP
- VPN Client Open VPN
- VPN Client PPTP
- VPN Client WireGuard
- VPN Server IPSec
- VPN Server Open VPN
- VPN Server PPTP
- VPN Server WireGuard
- VPN Fusion
Traffic Control :
- Adaptive QoS
• Bandwidth Monitor
• Bandwidth Limiter
-- Maximum Bandwidth Limiter Rule : 32 - Traditional QoS
-- Maximum Traditional QoS Rule : 32 - Traffic Monitor
• Real-time Traffic Monitor
• Wired Traffic Monitor
• Wireless Traffic Monitor - Traffic Analyzer
• Traffic Analysis Period : Daily, Weekly, Monthly
• Website History
WAN :
- Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP
3G / 4G LTE dongle - Port forwarding
• Maximum Port Forwarding Rule : 64 - Port triggering
• Maximum Port Triggering Rule : 32 - DMZ
- DDNS
- NAT Passthrough : PPTP Pass-Through, L2TP Pass-Through, IPSec Pass-Through, RTSP Pass-Through, H.323 Pass-Through, SIP Pass-Through, PPPoE relay
LAN :
- DHCP Server
- IGMP Snooping
- IPTV
- Manually Assign IP Address
• Maximum Manually Assign IP Address Rule : 64 - Wake on LAN (WOL)
Wireless :
- UTF-8 SSID
- WiFi MAC Address Filter
• Maximum MAC Filters : 64 - Wireless Scheduler
- Airtime Fairness
- RADIUS Client
- Universal Beamforming
- Explicit Beamforming
USB application :
- File System : HFS+, NTFS, vFAT, ext2, ext3, ext4
- Safely Remove Disk
- Download Master
- Media Server
- Time Machine
- Samba Server
- FTP Server
- Shared Folder Privileges
Administration :
- Configuration Backup and Restore
- Diagnosis tools
- Feedback System
- System Log
- New Device Connect Notification
- Login Captcha
- Connection Diagnosis
- Auto Firmware Update
